JK1224 vacuum transfer high definition five-color printing and die cutting machine

暂无价格
收藏
商品说明

Main features:

The whole machine is designed in accordance with the requirements for European reliability function and safety production.

Choose high quality materials and accessories, all roll material are of high quality steel, hard chrome plating, surface grinding.

Adopts gear grinding gear. Transmission gear with hard and grinding, rockwell hardness > 60 degrees.

Adopt keyless link, reduce the center wear, phantom amplifier, maintain long-term printing alignment.

Automatic zero, automatic reset.

Oil automatic balance device,. Keep the oil units at the same level.

Independent computer control, can store orders, fast to change orders, the operation more convenient.

Paper central dust collection system, seven dust removal device.

The whole machine each units can be a key separation or independent separation, operation more convenient, walk last warning bell ring, ensure the safety of operators.

Transfer roller, embossing roller, anilox roller is controlled by computer to adjust the clearance.

Main Bought-in Parts (from Good Famous Manufacturers )

1.Main motor

1)Main motor adopts frequency conversion motorSiemens

  2)Blower motor adopts frequency conversion motor,Siemens

2.Bearing

(Japan) NSK high speed bearing.

3.Electrical Parts

1)Each units adopt independent control unit, safe and reliable.

2)Relay, lights, buttons, contactor, air switch adopt(Germany) Siemens etc. good famous brand, to ensure reliable

3)Adjust frequency converter adopt Delta (main motor frequency conversion adjustment, suction feeding frequency adjustment)

4)PLC controller adopt  (Taiwan) delta

5)Rotary encoder adopt the Japan OMRON

6)Cylinders,pneumatic components using (TAIWAN) AIRTAC.

7)Solenoid valve adopt (TAIWAN) YADEKE.

8)Touch screen adopt(Germany) Siemens etc. good famous brand, to ensure reliable .

9)Rubber roller,(Hebei Jizhou yinxing)

10)Inking motor with (Taiwan) Chengbang motor

11)Die-cut rubber pad with  (Germany)DEPAIR.

12)Ceramic engraving roller adopts (guangzhou) guangtai.

13)The scraper system adopts kerou (guangzhou).

14)Die cutting independent servo drive, servo system using (Germany) Rexroth(optional)


1)Collection platform inclination height to be adjusted with the cartonstack height and the elevation motor incorporating electric braking

  function to keep the platform stable.

2)Paper-receiving carrier acts afterwards by carrying cardboard with automatically stretching collection plate when the cardboard are

  stacked up to the preset height.

3)Paper-receiving arm can be operated in electric or automatic mode.

4)Paper-receiving arm belt can be independently adjusted for tightness degree

5)Collection platform elevation to be driven by strong chains

6)Stacking height is 1700mm






















商品参数




规格model


925FFG

1228FFG

1428FFG

1628FFG


机器尺寸size

mm

920X2500

1250X2800

1400X2800

1600x2800

A


最大max

850

850

850

850

最小min

130

135

135

135

B


最大max

850

850

850

850

最小min

130

135

135

135

C


最大max

2420

2720

2720

2720

最小min

600

620

620

620

F

纸板长度

board length

最大max

2500

2800

2800

2800

Z

涂胶宽度

gluer width

最小min

40

40

40

40

X

箱高box height

最小min

70

80

80

100

H

纸板宽度

board length

最大max

920

1200

1400

1600

最小min

250

280

350

400


印刷面积

printing area

最大max

920X2500

1200X2700

1400X2800

1600x2800


模切面积

die cutting area

最大max

900X2500

1100X2700

1400X2800

1600x2800


未折纸板

not using board

最大max

1550

1650

1650

1650


最小机械速度

min machine speed

/

a piece of papaer/MIN

200

180

150

120


功率power

kw

22

29

40

40


机器重量

machine weight

(以实际为准)

TONS

25

35

41

45
